Chapter 3 How to Use

This chapter contains the following sections:

• Video Guide

• How to Use

• Display Resolution

Video Guide

Please scan the QR code or visit the link to watch the installation video.

• From Official Website: https://www.wavlink.com/en_us/video/ddb3e8abdf.html

How to Use

Before connection, please make sure that you have installed the driver from our website.

Step 1. Connect the host laptop to the USB-C upstream port.

Step 2. Connect five video ports (HDMI/DisplayPort) to your monitors.

Step 3. Connect the power adapter to the DC In, then plug the power adapter into a power source.

Display Resolution

Note:

1.Ensure your laptop’s USB-C port supports video output; otherwise, the HDMI (Alt. Mode) may not work.

2.For 4K@60Hz via HDMI (Alt. Mode), your laptop must support DP 1.4 via type-C port. With DP 1.2, it will be limited to 4K@30Hz.
