How to Connect

This chapter introduces the steps of connecting the docking station.

Ensuring the driver has been installed before using this Docking Station.

Step 1: Connect the host laptop to the USB-C Upstream port.

Step 2: Connect Display 1 (HDMI or DisplayPort) and Display 2 (HDMI or DisplayPort) to monitors.

Step 3: Connect one end of a power adapter to the Power Port, then plug the other end of it into the power outlet.

note

In Display 1 and Display 2, HDMI and DisplayPort ports cannot be used simultaneously, thus, only one port in each video stream group is available.
