Chapter 1 Overview
This chapter contains the following sections :
Product Overview
①2.4G Antenna Connectors
②5G Antenna Connectors
③Grounding Terminal
④Status LED
⑤WAN/LAN Port(PoE)
⑥Pair/Reset Button
Reset Button: Press and hold for 6s to restore the device to default settings.
Pair Button: Press and hold for 2s to pair with the existing Everything Mesh Wi-Fi system.
Basic Info
2.4G SSID: WAVLINK-AX_XXXX
5G SSID: WAVLINK-AX_5G_XXXX
Default IP: 192.168.30.1
Login: http://waplogin.link
Official Website: www.wavlink.com
Technical Support: support@wavlink.com
LED Indicator
| Mode | LED Status | Description |
|---|---|---|
| Mesh AP/Mesh Router Mode | Slow blinking | The device is in pair. |
| Mesh AP/Mesh Router Mode | Solid on | The device has connected to the Internet. |
| Mesh AP/Mesh Router Mode | Fast blinking | No Internet. |
| Repeater Mode | Slow blinking | The device has connected to the upstream router but no access to the Internet. |
| Repeater Mode | Solid on | The device has connected to the upstream router and the Internet has been connected. |
| Repeater Mode | Fast blinking | The device has not connecteed to the upstream router. |
| Mesh Extender Mode | Slow blinking | The device has connected to the upstream router but no access to the Internet. |
| Mesh Extender Mode | Solid on | The device has connected to the upstream router and the Internet has been connected. |
| Mesh Extender Mode | Fast blinking | The device has not connecteed to the upstream router. |
| AP Mode | Solid on | The device has connected/disconnected to the Internet. |
